Texsource
Texsource GEN Series Plastisol Ink - Black (11900)
- SKU:
- 11900
- MPN:
- 11900
- Weight:
- 12 LBS
- Shipping:
- Calculated at Checkout
Description
Texsource GEN Series Plastisol Ink - Black (11900)
High-density standard black plastisol formulated for rich opacity, sharp halftone detail, and rapid wet-on-wet production. Perfect for direct textile printing across cotton, 50/50 blends, tri-blends, and conventional cold-peel heat transfers.
RECOMMENDED MESH
FLASH PROFILE
FUSION CURE TEMP
SQUEEGEE SELECTION
Fabric Compatibility & Substrate Performance
Approved Ink Modifiers & Mixing Versatility
The Texsource GEN series integrates smoothly with standard commercial additives. For special applications, modify with curable reducers (for decreased squeegee drag on 230+ mesh halftones), stretch additives (for athletic ribbing), puff concentrates, or thickeners. Always follow specific manufacturer additive ratios to maintain the low 285°F cure balance.
Press Performance & Production Advantages
Texsource GEN Series Black (11900) represents advanced plastisol ink technology engineered specifically for commercial screen printers. Formulated as a general-purpose, high-density black, this ink provides exceptional printability, crisp line definition, and high-productivity wet-on-wet performance on both manual carousels and high-speed automated presses.
*Product photos are visual representations of ink body and viscosity. Standard textile black is formulated for general purpose, deep-absorption textile printing.
Texsource GEN 11900 Black is a true industry-standard textile black pigment engineered for high-density coverage, text work, spot color outlines, and fine halftone key plates.
- High-Density Black Pigment: Delivers pure, rich jet-black prints without washing out to a charcoal or brownish tint on cotton or synthetic garments.
- High-Productivity Wet-on-Wet Formula: Formulated to resist screen buildup on the contact side, allowing seamless wet-on-wet automated runs without intermediate flashing.
- Energy-Saving 285°F Low Cure: Achieves full fusion cure at 285°F (~60s dwell), protecting synthetic fibers, saving shop electricity, and minimizing garment shrinkage.
- Dual Application Versatility: Excels as a direct textile ink on cotton, 50/50, and tri-blends, while also serving as a dependable medium for conventional cold-peel transfers.
Technical Press & Curing Specifications
| Variable | Factory Specification | Shop Floor Standard |
|---|---|---|
| Color / Code | Standard Black (SKU: 11900) | High-density standard press black |
| Chemical Formulation | Non-Phthalate General Purpose Plastisol | Wet-on-wet direct print & transfer compatible |
| Full Fusion Cure Temp | 285°F (140°C) | Approximate 60-second dwell time across ink film |
| Flash Profile | 220°F – 240°F (105°–115°C) | Tack-free flash gel in 1–2 seconds |
| Emulsion Compatibility | Pure Photopolymer, Dual-Cure, Diazo | Universal compatibility with plastisol stencils |
| Cleanup Solvent | Screen Wash / Plastisol Ink Remover | Clean with standard press wash & PPE |
| Packaging Options | Quart, 1 Gallon, 5 Gallon Pail | Store tightly sealed at room temperature |
Troubleshooting & Pressroom Defect Prevention
Resolving common shop-floor printing issues with Texsource GEN Series Black:
Issue: Why is Black ink washing out or graying out after laundry cycles?
Correction: Black absorbs radiant dryer heat quickly, which often fools press operators using infrared guns. The surface reaches 285°F rapidly, but the full depth of the ink deposit where it bonds with garment fibers must maintain 285°F (140°C) for ~60 seconds. Always verify internal dwell with a thermal donut probe.
Issue: How do I avoid dot gain and screen clogging when printing black halftones or key lines?
Correction: For fine simulated process key lines or halftones, use a 230–305 tpi mesh count. If necessary, mix in 1–2% Curable Reducer by weight to lower ink viscosity and ensure clean mesh release without causing dot gain or bleeding on garments.
Issue: Why are colors printed on top of flashed black flaking off after cure?
Correction: Because black absorbs infrared heat much faster than other pigments, it is very easy to over-flash. Over-flashing fully cures the black ink surface, preventing secondary inks from cross-linking. Keep flash temperature between 220°F–240°F just until the film is gelled and tack-free to the touch.
Complete Your Pressroom Workflow
Matched press chemistry, modifiers, and screen room supplies engineered for Texsource GEN Inks:
Curable Viscosity Reducer →
Loosen ink body without sacrificing curing stability or film integrity.
On-Press Screen Wash →
Fast-evaporating press wash for quick color changes and tape-clearing.
Texsource Tex-Blue Emulsion →
High-solids pure photopolymer emulsion for razor-sharp edge definition.
65/90/65 Triple Squeegee →
Composite triple blade delivering sharp shear without blade rollover.
Screen Printing Industry News and Information
Industry news, educational resources, best practices, and practical screen room protocols provided by ScreenPrintingInsights.com.
DISCLAIMER, COLOR REPRODUCTION & STORAGE NOTICE: Texsource is a registered trademark of its respective owner. Star Graphic Supplies is a distributor of Texsource screen printing inks and products. On-screen ink swatches and product photos are digital representations intended for reference only and must not be used for graphic design color-matching or equipment calibration. Keep containers tightly closed when not in use. Store at room temperature between 65°F–80°F (18°C–27°C). Protect from direct sunlight and radiant conveyor dryer heat. Always perform wash, stretch, and cure tests prior to production runs.
